The working height of the Cherry picker spider lift can reach up to 22m, the load is 200kg, and the platform size is 0.9*0.7M. Multifunctional, multipurpose work device. Through the front bracket of the boom, the lifting device or the manned platform can be quickly installed to realize the functions of material lifting, hoisting and manned aerial work, etc.
Model Type | CTA-10A | CTA-12A | CTA-14T | CTA-16T | CTA-18T | CTA-20T |
Version | Articulated | Articulated | Telescopic | Telescopic | Telescopic | Telescopic |
Lifting height | 10M | 12M | 14M | 16M | 18M | 20M |
Working height | 12M | 14M | 16M | 18M | 20M | 22M |
Load Capacity | 200KG | |||||
Platform size | 0.9*0.7M | |||||
Working radius | 5.5M | 6.5M | 8.5M | 10.5M | 11M | 11M |
Net Weight | 1855KG | 2050KG | 2500KG | 2800KG | 3000KG | 3100KG |
Overall Size( L*W*H) | 5.2*1.7*2.1M | 6.2*1.7*2.1M | 5.6*1.7*2.1M | 5.7*1.7*2.2M | 6.5*1.8*2.3M | 5.8*1.9*2.3M |
Details Images:
(Germany) Alko Brakes
Swivel Stand (Adjustable Height)
Auxiliary Wheel
Triangular Structure
Precision Connection Point
Boom Pressure Relief Valve
Outrigger Locks (To Prevent Shaking When Moving)
Diesel Motor(Ysd)
Durable Pneumatic Tires
Car Tail Light
Seat Belts Secure The Body
Control Room
Torsion Shaft
Fuel Tank
Two Service Doors
Filter Alarm System
Tilt Sensor
Control Panel
Manual Accelerator
The Electromagnetic Valve
Outriggers Control Switch
Basket With Ladder
Platform Control System
Warning Light
Main Cylinder
Arm Cylinder
Jlb
Self-Balancing Outriggers
Self-Balancing Outrigger Cylinder
Battery Only For Dc Power
Maintain Security Rules:
1. The equipment should be operated and maintained by trained personnel.
2. After the first use of the platform and 200 hours of operation, the hydraulic oil should be replaced and the filter element should be cleaned. In the future, under normal circumstances, the oil should be cleaned and changed every six months, and the oil change cycle should be shortened as appropriate when used in places with a lot of wind, sand, and dust. Use No. 32 anti-wear hydraulic oil in winter and No. 46 anti-wear hydraulic oil in summer.
3. When the platform is used for the first time or after long-term storage, each mechanism should be operated repeatedly without load to discharge the air in the hydraulic system. If necessary, the oil pipe joint can be loosened to discharge the air, and then the joint should be tightened after release.
4. Frequently check whether the hard pipes and hoses of the oil circuit are abnormally deformed and damaged, whether the pipe joints and the operation valve interface are leaking oil, and if any problems are found, they should be dealt with in time.
5. When the equipment is not in use, it is necessary to add a dust cover and store it properly. When the platform is not used for a long time, it should be sealed and stored, and the outriggers can be put away during storage. And check once a month, inflate the tires according to the regulations, run the platform without load once a month, check the operation of each mechanism, and deal with problems in time if found.
6. According to the frequency of use of the platform, check and maintain frequently.
【1】Check whether the pin nuts at the joints of the platform are loose or fall off.
【2】Check whether the hydraulic pipeline is broken, and whether the joints are leaking or loose.
【3】Check whether the electrical circuit is connected or exposed.
【4】Check whether the joints of the electric control box are loose, and whether the indicator light is working normally.
【5】Check whether the operation of each control handles and button is flexible.
【6】Check whether the limit switch is loose or damaged.
【7】Check the lubrication condition of each pin shaft and inject enough lubricating oil.
