Shandong Cathay Machinery Co., Ltd. is one of the most experienced manufacturers and suppliers of small all crawler boom lift in China. We warmly welcome you to buy discount small all crawler boom lift for sale here from our factory. Quality products and reasonable price are available.
small all crawler boom lift
CATHAY brand Small All Crawler Boom Lift boasts compact structure and strong off-road performance. This Small All Crawler Boom Lift adopts durable crawler design, adapting to muddy, sloped and uneven ground easily.
The flexible arm design makes this Small All Crawler Boom Lift access hard-to-reach working spots freely. Dual power choices satisfy indoor and outdoor operation needs. With full safety configurations and sturdy build, it works stably for construction maintenance, landscape trimming and engineering installation. All products comply with CE standard, reliable quality brings long service life.
Product Details
Key Advantages of CATHAYLIFT Platform Basket Spider Lift
-
Extensive Operation Coverage & Solid Bearing Performance This Small All Crawler Boom Lift supports working height from 12m to 24m and bears maximum 227kg weight. It fully fits various aerial tasks including equipment installation, building maintenance and surface cleaning.
-
Flexible Crawler Structure & Space-Saving Outline Equipped with wear-resistant rubber tracks, the Small All Crawler Boom Lift travels smoothly on rugged slopes, lawns and rough ground. Slim body size enables entry into narrow lanes, no professional driving certificate needed.
-
Secure Lifting Performance & Comprehensive Safety Guard The Small All Crawler Boom Lift is fitted with automatic leveling hydraulic legs and 359° rotating table. Anti-fall structure, tilt monitoring and emergency relief valves effectively avoid operational risks.
-
Diversified Power Supply & Low Daily Maintenance Available electric, diesel, gasoline and hybrid power modes. It adapts to enclosed indoor sites and open outdoor construction scenes, cutting later maintenance cost greatly.
-
User-Friendly Intelligent Control System Multilingual LCD touch screen and anti-error operating buttons simplify manipulation. Remote control function realizes accurate positioning and flexible moving, easy for novice operators.
-
Standard Certified Quality & Customizable Configuration Conforming to CE safety norms, the crawler boom lift comes with two-year quality guarantee. Optional lithium battery, overload protector and swing basket satisfy personalized usage requirements.
Application
Real Order
|
Model Type |
CTA-12TC |
CTA-14TC |
CTA-16TC |
CTA-18TC |
CTA-20TC |
CTA-22TC |
|
Lifting height |
10M |
12M |
14M |
16M |
18 |
20 |
|
Working height |
12M |
14M |
16M |
18M |
20 |
22 |
|
Load Capacity |
227 KG |
|||||
|
Platform size |
0.9*0.8M |
|||||
|
Working radius |
5.5M |
6.5M |
8.5M |
10.5M |
11M |
11M |
|
Net Weight |
1855KG |
2050KG |
2500KG |
2800KG |
3500KG |
3800KG |
|
Overall Size( L*W*H) |
5.2*1.35*2. 1M |
6.2*1.35*2. 1M |
6.1*1.35*2. 7M |
6.5*1.35*2. 85M |
6.8*1.35*2. 9M |
7.2*1.35*2. 95M |
|
Electric Motor |
48V/3.3kw |
|||||
|
Battery |
8*12V/230Ah |
|||||
|
Wind Resistance Level |
5 |
|||||
